This page contains the connector pinout information for the VBOX Mini LapTimer units (RLVBLAPMINI), including power, RS232/CAN, and GNSS antenna connections.
Use the pinout tables to identify connector functions and wiring requirements when integrating the unit with external power supplies, CAN systems, or compatible accessories.
This page contains the connector pinout information for the VBOX Mini LapTimer units (RLVBLAPMINI), including power, RS232/CAN, and GNSS antenna connections.
Use the pinout tables to identify connector functions and wiring requirements when integrating the unit with external power supplies, CAN systems, or compatible accessories.
| PIN | I/O | Function |
|---|---|---|
| Centre | I | RF Signal/Power for active antenna |
| Chassis | I | Ground |
| PIN | I/O | Function |
|---|---|---|
| Centre | I | RF Signal/Power for active antenna |
| Chassis | I | Ground |
| PIN | I/O | Function |
|---|---|---|
| 1 | I | RX |
| 2 | O | TX |
| 3 | - | Ground |
| 4 | I/O | CAN Low |
| 5 | I/O | CAN High |
| 6 | - | Power |
| PIN | I/O | Function |
|---|---|---|
| 1 | I | RX |
| 2 | O | TX |
| 3 | - | Ground |
| 4 | I/O | CAN Low |
| 5 | I/O | CAN High |
| 6 | - | Power |
